Isolierkörper | Thermoplastischer Kunststoff, nach UL94 V-0 |
---|---|
Kontaktmaterial | Vierkantstift 0,50mm, Kupferlegierung |
Kontaktoberfläche | Lt. Oberflächenoptionen, über Ni (1,3 ... 2,5µm) |
Lötbarkeit | IEC 60512-12A |
Durchgangswiderstand | < 20mΩ |
Isolationswiderstand | > 1000MΩ |
Spannungsfestigkeit | 500VAC |
Nennspannung | 125VAC |
Nennstrom | 1A |
Temperaturbereich | -40°C ... +85°C |
Verarbeitung | Wellen- oder Reflow-Lötverfahren |
Series | Contacts | Type | Plating |
---|---|---|---|
635 | 16 | 1 | 00 |
10 12 14 16 20 22 24 26 30 32 34 36 40 44 50 60 64 68 |
1 Gerade 2 Gewinkelt |
00 Au Flash 60 Sel. Au/Sn |
