Isolierkörper | Thermoplastischer Kunststoff, nach UL94 V-0 |
---|---|
Kontaktmaterial | Vierkantstift 0,40mm, Kupferlegierung |
Kontaktoberfläche | Lt. Oberflächenoptionen, über Ni (1,3 ... 2,5µm) |
Lötbarkeit | IEC 60512-12A |
Durchgangswiderstand | < 20mΩ |
Isolationswiderstand | > 500MΩ |
Spannungsfestigkeit | 500VAC |
Nennspannung | 250VAC |
Nennstrom | 1A |
Temperaturbereich | -40°C ... +105°C |
Verarbeitung | Wellen- oder Reflow-Lötverfahren |
Series | Height | Contacts | Type | Dimensions | Plating |
---|---|---|---|---|---|
712 | 1 | 008 | 1 | 20 | 60 |
1 H=1,00mm 2 H=1,60mm 4 H=2,50mm |
004-100 Zweireihig |
1 Gerade 2 Gewinkelt |
Gerade 10 B=2,70 C=2,60mm 20 B=3,00 C=3,00mm 99 Kundenspezifisch Gewinkelt 10 B=3,05mm 20 B=1,91mm 99 Kundenspezifisch |
00 Vergoldet 50 Verzinnt 60 Sel. Au/Sn |
